Jolida hybrid tube amplifier


Jolida JD1701A

Technical Specifications:
Rated Output Power:
50 W per channel at 8 ohms, 22Hz to 19KHz

Frequency Response:
(at 1 watt into 8 ohms) 5Hz to 100KHz + 1dB

22Hz to 19kHz + 3dB; 0dB 50 W 1KHz

Distortion THD:
Less than 0.1% at 50 W output, 22Hz to 18KHz

Input Impedance:

Input Sensitivity:
500mV at 1KHz and 8 ohms for 50 watt output

Noise and Hum:
90dB below rated output

Tube Complement:
2 pcs. 12AX7 for the preamplifier.

Power Requirements:
110V-120 VAC 60Hz 180 watts-standby, 450 watts maximum (220 VAC 50Hz option).

17 inches wide by 13 inches deep by 4 inches high

30 pounds net, approximately 33 pounds packaged.

18 months limited parts and labor. Six months or 1000 hours whichever comes first on Jolida Tubes.

110 - 120 VAC, 3.5 Amp Fast Blo; 200 - 240 VAC, 3.5 Amp Fast Blo
